Factory price Three Phase Smart Multifunction Network Electric Power Meter

Model NO.: RH-D5Y
Price:: US $ 32.87-32.87 / piece
Delivery: FOB Shanghai, Ningbo
Minimum order quantity: 1 piece
Supply Ability: 10000 piece / Week
Country of Origin: Zhejiang, China

Quantity:

Product Description

Color:Black
OEM:Yes
Power consumption:<1VA
Communication:RS485 Modbus
Display:LCD Display
Frequency:45~65Hz
Save temperature:-20℃~+75℃
Baud Rate:1200-38400(Factory default: 9600)
Relative humidity:<80%RH
Warranty:1 Year
Display Type:Digital Only
Phase:Three Phase
Brand Name:REHE
Output Voltage:AC 220V
Model Number:RH-D5Y
Dimensions:96*48
Operating Temperature:-10℃~+55℃
Measuring Energy Range:0-9999
Accuracy Class:0.5, 0.2

Foreword

Thanks for using our company products. We will provide reliable quality and dedicated service to allow you to rest assured to use our company products. Before installation, circuit connection, running and maintenance, please make sure to read carefully the user manual, to ensure the correct using, during using please also make sure know very well of relative safety and caution items.


Model	Size	Measurement range (Voltage)	Measurement range (Current)	Connection
RH-D5Y	96*48	380V/100V	5A/1A	Three phase four wires/ three phase three wires
RH-D3Y	96*96	380V/100V	5A/1A	Three phase four wires/ three phase three wires
RH-D2Y	120*120	380V/100V	5A/1A	Three phase four wires/ three phase three wires
